GlowStack is a compact, modern table lamp designed to bring warm, atmospheric light to any corner of your home.
Its stacked, offset-ring lampshade creates a soft spiral glow, while the slightly tilted base adds a unique, dynamic character.
Printed in two parts, GlowStack blends simplicity, style, and functionality into a clean, eye‑catching design.

📦 Parts Included

• 1× Base
• 1× Paralume

📐 Technical Specifications

• Total height: 126 mm
• Base diameter: 100 mm
• Compatible LED bulb: Ø 60 mm (A60 LED)
• Recommended bulb ASIN: B0G8HB98DF
• Lampshade wall thickness: 1.04 mm

Recommended materials:

• Base: Matte PLA, terracotta‑style PLA, or any opaque filament
• Lampshade: White PLA or translucent PLA for best light diffusion

🖨️ Printing Guidelines

Base

• Supports: Not required
• Orientation: Print flat on the build plate
• Note: The top surface is intentionally tilted, not parallel to the table

Lampshade

• Supports: Required
• Orientation: Vertical
• Layer height: 0.2 mm recommended
• Infill: 10–15%
• Material: White or translucent PLA

💡 Lighting

• Designed for a 60 mm LED bulb (A60)
• Recommended bulb ASIN: B0G8HB98DF
• Easy internal installation
• Produces a warm, diffused ambient light ideal for evening settings

🖼️ Design Features

• Offset stacked rings create a spiral light effect
• Tilted base for a modern, sculptural look
• Compact size suitable for desks, shelves, and bedside tables

🛠️ Notes

Designed by Vinors 3D Lab – 12/03/2026
DWG No. F — Rev. 1 — Sheet 1/4
